20 SQ. FT. ALFA LAVAL SPIRAL HEAT TUBES
20 SQ. FT. ALFA LAVAL SPIRAL HEAT TUBES
$1,500 (USD)
or
Call (303) 423-2332
Description
20 SQ. FT. ALFA LAVAL SPIRAL HEAT TUBES, 4" SPIRAL TUBE INSIDE 6" SHELL
Specifications
| Manufacturer | ALFA LAVAL |
| Model | U10T6x20 |
| Condition | Used |
| Stock Number | HX-159 |
| 20 sq. ft. alfa laval spiral heat tubes. type | U10T6X20. |
| Temp in | 185 DEG F. |
| Temp out | 100 DEG F. |
| Outer shell/tube side fittings | 4'' TRI-CLAMP CONNECTIONS. |
| Length tube | 234''. |
| Max design pressure | SHELL 150 PSI, TUBE 250 PSI. |
| Max design temp | SHELL 300 DEG F, TUBE 200 DEG F. |
| Area | 20.41 SQ FT. |
| Shell side vol | 13.71 US GAL. |
| Tube side vol | 11.41 GAL |
